Erick Miracle Point – Centering Tool 900-02 CW

Displays 0-90-180-270–0 indicating full 360degrees
Reading angles from the horizontal plane in a counter-clockwise direction is commonly used on pipe benders.NSN:5210-01-576-2924

This is one of the fastest, most accurate ways to mark the center of a round, square, hex oval, or almost any shape that fits into the “V” leg

• Fast, precise measurements
• Dial face indicates 0-90-180-270-0
• Read 0-360 in counter-clockwise direction

Works as a magnetic base protractor, level, centering head, centering punch, or pipe centering tool great for pipe fitting and welding

• The Centering tool has a solid brass movement, which gives an immediate reading of angles for a 360-degree radius.
• The V base is welded together and then precision milled, and it is very durable.
• It exerts a powerful magnetic pull, and the center pin hardened to RC 59/63 will show the middle point at the indicated angle.
• Accurately marks center point to be drilled, milled, welded…

Extra features include:

• Certificate of calibration included with new or reserviced units Guaranteed 1 year +/- .5 degree
• All instruments have been calibrated and include a certificate of calibration, which is NIST traceable. They also come with a one-year service calibration warranty. Made in the U.S.A.

Note: for reading angles from “0” degree in a counter-clockwise direction only pictured above
